WILSON COMBAT
1911 BEAVERTAIL FITTING JIG

874218001735 965402000

Élimine les conjectures lors de l'ajustement du beavertail

Fournit un guide précis pour couper les tangs du cadre sur les cadres 1911 Auto ; facilite l'installation des beavertails Wilson High-Ride. Installez sur le cadre et limez jusqu'au guide ; la lime ne coupera pas le gabarit durci. Retirez le gabarit et poncez ou limez pour ajuster.

SPECS : Acier, brut, durci. Comprend le gabarit, les fixations et les instructions. S'adapte aux beavertails Wilson et Clark.

Plus...

Takes The Guesswork Out Of Beavertail Fitting

Provides a precise guide for cutting the frame tangs on 1911 Auto frames; makes short work of installing Wilson High-Ride Beavertails. Install on frame and file up to guide; file will not cut the hardened jig. Remove jig and sand or file to fit.

SPECS: Steel, in-the-white, hardened. Includes jig, fasteners and instructions. Fits Wilson and Clark beavertails.

Plus...

Évaluations client de WILSON COMBAT BEAVERTAIL FITTING JIG

Nombre d'évaluations: 6
De brownells.com: 6
Note moyenne: 4,3

Easy to use, but labor intensive (11/10/2009)

When drop in beavertails aren't available, you should use a jig - one with the same radius as the new beavertail for best fit. Should buy beavertail & jig made by same company. Provided instructions were pretty basic, but intuitive - mount jig & cut frame to jig surface. At that point, you're not finished. Must trim frame a bit at a time until holes in frame & jig line up. Then finish triming the beavertail tab (the hardest part) to make grip safety/trigger/sear/hammer work. Use old grip safety for reference.
Pics on my instructions were poor to black, but not really needed. Cutting can be done w/fine hobby bench grinder, fine files, & Cratex tools. Metal on jig is very hard & difficult to damage. First job took long time, next will be 1/2 as much. Came out really nice for my first job as a rank amateur.

Great tool! (19/06/2011)

I have fit BT safeties in the past by hand and it took a long time to get it done and look good. Using this tool it took about 1 hour from start to final lapping of the safety. The jig is super hard and the file just bounces off of it. It will get you close then some layout fluid or permanent marker and test to get that last whisker of metal removed and have a perfect fit.

The only downside is the instructions. They pretty much are useless.

Great Tool (21/10/2011)

Great tool and very easy to use, simply screw it on the frame and file till you hit the jig. The Jig will get you about 95% of the way to a perfect fit, the other 5% is slow freehand filing. I used this with a wilson beavertail for a perfect fit.

Wonderful tool (16/12/2011)

This jig made my beavertail fitting time go from 3 hours to 1. once done with the file I only needed to fine tune a couple high spots and hit it with some emery cloth. I used wilsons beavertail and it fit perfectly

Nice little piece. (24/04/2012)

This is a nice little jig that will make things a lot easier fitting the beavertail on my Officers ACP though i must say that the instructions are a joke, why even think of including example pictures when they are just black smears on the paper.. Seriously.

Great product for W. C. Beavertails (26/02/2017)

This is a must have product if you are going to install a Wilson Combat Beavertail. The instructions can be better however after a little investigation itâs easy enough to understand. I rated this 4 out of 5 stars as I've used this on several model 1911's and on a few, some additional prep work was needed in order to make the grip function properly.

Lire 6 plus d'avis sur brownells.com

45.9 45.9 1 EUR

Référence: 965402000
WILSON COMBAT BEAVERTAIL FITTING JIG
Ref Fabricant: 402 874218001735 Fournit un guide précis pour couper les tangs du cadre sur les cadres 1911 Auto ; facilite l'installation des beavertails Wilson High-Ride. Installez sur le cadre et limez jusqu'au guide ; la lime ne coupera pas le gabarit durci. Retirez le gabarit et poncez ou limez pour ajuster.

45.9 EUR 0 45,90 € *

En rupture de stock, environ 4-12 semaines à partir de l'entrepôt principal.

Caractéristiques: Fabrication: 1911

Ajouter à la Liste d'Envies

Poser un question

Propriétés

Ajouter à la Liste d'Envies

Poser un question

Points forts

Facilite l'installation des queues de castor Wilson High-Ride sur les pistolets 1911 Auto.
Guide précis pour découper les pattes de crosse sans endommager le gabarit trempé.
Comprend gabarit, fixations et instructions pour un ajustement facile.

Caractéristiques

Fabrication: 1911 Poids du colis: 0,041kg Hauteur d'expédition: 18mm Largeur d'expédition: 79mm Longueur d'expédition: 122mm UPC : 874218001735
