L'un des aspects les plus difficiles pour ajuster un pad de recul a toujours été l'ajustement final du pad au bois, car il est très facile d'endommager la crosse avec le disque, la bande abrasive ou la lime - et de ruiner la finition. Le B&R Recoil Pad Fitting Jig élimine le risque d'endommager la crosse en vous permettant de terminer le pad complètement à l'écart de la crosse. Le Jig est composé de deux pièces de base : (1) un triangle ajustable sur lequel le pad est monté pour être ajusté à la taille, et (2) un support universel qui se fixe à la table du disque de ponçage. L'utilisation est simple. Tout d'abord, coupez la crosse à la longueur et à l'angle nécessaires pour s'adapter au client. Fixez le pad à la crosse et tracez clairement le contour de la crosse sur le pad. Ensuite, transférez le pad sur la plaque de base du Jig, réglez l'angle d'inclinaison, placez le Jig sur son support et ajustez le pad juste au-dessus de la ligne tracée (c'est nécessaire car la ligne a été dessinée à l'extérieur de la crosse). Enfin, testez l'ajustement du pad sur la crosse et effectuez les derniers ajustements à la main, si nécessaire. Les lignes de la crosse se prolongent correctement dans le pad - et vous obtenez un ajustement parfait ! Le Jig élimine tout dommage à la finition de la crosse et réduit l'ensemble de l'opération de montage du pad à un exercice simple de 15 minutes - rendant le travail facile et très rentable.
SPÉCIFICATIONS : Le support en acier mesure 20-1⁄4" (51,4 cm) de long. Les pieds en triangle en acier mesurent environ 11-1⁄4" (29,2 cm) de long. La plaque de base en aluminium mesure 3-1⁄2" (9 cm) de long. Comprend des instructions.
One of the most difficult aspects of fitting a recoil pad has always been the final fitting of pad to wood because it is so easy to hit the stock with the disc, sanding strip, or file - and ruin the finish. The B&R Recoil Pad Fitting Jig removes the risk of stock damage by letting you finish the pad completely off - and away from - the stock. The Jig is composed of two basic pieces: (1) an adjustable triangle on which the pad is mounted to be dressed to size, and (2) a universal support that attaches to the sanding disc table. Operation is simple. First, cut the stock to the length and pitch required to fit the customer. Attach the pad to the stock, and sharply scribe the outline of the stock on the pad. Then transfer the pad to the base plate of the Jig, set the angle of pitch, put the Jig on its support, and dress the pad to the point of just removing the scribed line (this is necessary as the line was drawn outside the stock). Finally, test fit the pad to the stock and do any final dressing by hand, if needed. The lines of the stock are carried correctly into the pad - and you have a perfect fit! The Jig eliminates all damage to the stock finish and reduces the entire pad mounting operation to a simple 15 minute exercise - making the job an easy and highly profitable one.
SPECS: Steel support is 20-1⁄4" (51.4cm) long. Steel triangle legs are approximately 11-1⁄4" (29.2cm) long. Aluminum base plate is 3-1⁄2" (9cm) long. Includes instructions.
